Brand:MIC
deliver goods:Within 3 days
MIC-2000D slit lamp microscope
Configuration:
• Slit lamp
• Camera interface (splitter / adapter)
• Professional SLR camera (standard configuration does not contain a camera lens)
• Bolan slit lamp image processing systerm
• Computer (optional)
• High-resolution ink-jet printer (optional)
Technical Parameters
|
Microscpe |
Microscope Type |
Converging Stereoscope Microscope |
|
Magnification Selection |
2 step magnifications |
|
|
Eyepiece |
10x |
|
|
Magnification Ratio |
10×（φ18） |
|
|
Diopter Adjustment |
50mm ~ 82mm |
|
|
Pupillary Adjustment |
+5D ~ -5D |
|
|
base |
Side Shift |
110mm |
|
Depth Shift |
90mm |
|
|
Height Shift |
30mm |
|
|
Chin rest |
Height Shift |
80mm |
|
Fixation Target |
Red LED |
|
|
Illumination System |
Slit width |
0 ~ 10mm continuous (at 10mm,slit becomes a circle ) |
|
Slit Height |
Ф10mm 、Ф3mm、 Ф1mm 、 Ф0.2mm |
|
|
Filter |
Heat absorption ,Red-free , Cobalt Blue |
|
|
Illumination Bulb |
12V 50W halogen lamp |
|
|
Power |
Input Voltage |
220V/110V |
|
Frequency |
50H/60Hz |
|
|
Power Consumption |
68VA |
|
|
Weight and size |
G.W |
13kg |
|
N.W |
11kg |
|
|
Main Dimension |
455mm（L）× 385mm（W）× 630mm（H） |
