Optical system

Finite color corrected optical system

Head

Monocular head 30°inclined, with locking system

Binocular head 30°inclined, 360° rotatable  with locking system,

right eyepiece tube diopter adjustable, ±5D interpupillary distance 50-75mm

Trinocular head,30°inclined, 360° rotatable,

Interpupillary distance:50-75mm,beam splitting ratio R:T=5:5

Eyepiece

Wide field plan eyepiece PL10X/18mm, reticle, pointer optional

Objective

Achromatic objective (4X、10X，40X，100X)

Plan achromatic objective (4X、10X、20X、40X、100X)

Nosepiece

Reversed quadruple nosepiece

Main body

Low position coaxial coarse and fine adjustment, Coarse adjustment range 13 mm

(double layer stage 7mm), precision of fine adjustment:2um with locking system

0.2W LED illumination (color temperature 5700-6500K),

brightness adjustable. Battery charging system is optional

input 100V-240V , output 5V 1A

Stage

Single stage, size 110mm×120mm with two clips,

single lens condenser N.A=0.65, five hole iris diaphragm plate

Double layer mechanical stage: 115mmX125mm ABBE condenser N.A.=1.25,

with iris diaphragm, with fish eye lens holder

C mount

0.35X/0.5X/0.65X/1X C-mount, focus adjustable
