Brand:MIC
Mini Order:1
deliver goods:Within 3 days
Binocular head, to 1600X mag, mechanical stage, N.A.1.25 condenser,
1W (3W)LED, 195 Achromatic objective 4X, 10X, 40X, 100X,
|
MIC-B30 serials Biological microscope technical specification |
|||||
|
Technical specification |
Model |
||||
|
MIC- B30-M |
MIC- B30-B |
MIC- B30-T |
MIC- B30-TR |
||
|
Total magnification: 40X～1600X |
|||||
|
Viewing head |
monocular head: 30° inclined |
● |
|||
|
articulated binocular head,30°inclined,360° rotated |
● |
||||
|
articulated trinocular head,30°inclined,360° rotated |
● |
||||
|
articulated trinocular head,30°inclined,360° rotated, teaching head |
● |
||||
|
Eyepiece |
wile-field eyepiece :WF10X/18mm |
● |
●● |
●● |
●● |
|
wild-field eyepiece :WF16X/15mm |
○ |
○ |
○ |
○ |
|
|
Nosepiece |
revolving quadruple nosepiece |
● |
● |
● |
● |
|
Objective |
195 achromatic objectives:4X,10X,40X（S）,100（O,S） |
● |
● |
● |
● |
|
195 achromatic plan objectives:4X,10X,40X（S）,100（O,S） |
○ |
○ |
○ |
○ |
|
|
Mechanical stage |
115x125mmdouble layer mechanical stage, moving range70mm(X)x30mm（Y）with double section clamp |
● |
● |
● |
● |
|
Focusing |
Coaxial focus system with upper limited and tension adjustment; coarse adjustment range:20mm, fine adjustment precision:0.002mm |
● |
● |
● |
● |
|
Condenser |
N.A.1.25 condenser |
● |
● |
● |
● |
|
Illumination |
1W LED illumination, brightness adjustable or 6V/20W, 6V/30W halogen lamp |
● |
● |
● |
● |
|
Filter |
yellow, green, blue, neutral color filter |
● |
● |
● |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
