The MIC-CD6B is the bran-new multifunctional operation microscope of Chongqing MIC Technology Co,Ltd. It have perfect optics system and the biggest depth of field. It can be used in ophthalmology surgery, Neurosurgery, dentistry, Orthopedics, E.N.T Dept.

Specification

Eyepieces

magnification 12.5x, pupil distance adjustable range 55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens 180mm.

Binocular tube

30°~90°variable angle binocular tube, add new pupil distance adjustment

Magnification

6:1 zoom, motorized, magnification 5.1x~30.6x; field of view Φ45~Φ7.5mm

Coaxial assistant’s binocular tube

manual 3-step changer, total magnification 6.4x,10.8x,17.3x; field of view Φ31mm,Φ19mm,Φ12mm

Coaxial illumination

illumination diameter of light spot Φ50mm, illumination intensity 100000lux

Oblique illumination

illumination range 50mm,illumination intensity 25000lx

Objectives

f 200mm (175mm, 250mm etc )

Focusing

motorized, range +/-25mm, speed 33s/whole distance

X-Y translator

move in X-Y direction motorised, range +/-30mm

Maximum length of arm

1200mm

Stand

swing angle of the carrier arm 0 ~300°,height from objective to floor 800mm

Foot switch

waterproof, 8 function steps

Weight

164kg
