| Features |
| 1. 23HP American Briggs & Stratton VANGUARD gasoline engine. International warranty local service. |
| 2. Italian imported hydraulic parts. Makes HY200 mini loader high configuration and big working flow. |
| 3. Joystick handle. Operating smoothly and comfortably. |
4. Steering wheel operated and clear instructions.
|
| 5. One left pedal for attachments' lock-in. Two right pedals control machine's speed, stopping and back up. |
| 6. Articulated steering chassis, drive easily. Seat with safety belt, safe and comfortable. |
| 7. Quick hitch joints, HY200 mini loader can attach bucket, digger, auger, backhoe, hydraulic breaker, pallet forks, angle broom, sweeper,lawn mower, snow blower, stump grinder, tree spade, 4 |
| Specification |
|
1)Size |
|
|
Dimension(L*W*H) |
2430mm* 1080mm* 2045mm |
|
Max pin height(B) |
1755mm |
|
Max dumping height(C) |
1295mm |
|
Max point dumping distance(D) |
430mm |
|
Ground clearance(F) |
210mm |
|
Wheel base(G) |
1207mm |
|
Bucket Width |
1150mm |
|
Total Length without Bucket(J) |
2015mm |
|
Departure angle(α) |
40° |
|
Bucket discharge angle |
37° |
|
Turn Radius forward Turning |
2030mm |
|
2)Engine |
|
|
Rated Power (KW) |
17.15KW(23HP) |
|
Type |
Gasoline |
|
3)Hydraulic System |
|
|
Pressure |
17Mpa |
|
Operating Load |
260kg |
|
Bucket Capacity |
0.15m³ |
|
Travel Speed |
0-8km/h |
|
Weight |
900kg |
|
Fuel tank capacity |
27.45L |
|
Hydraulic oil tank capacity |
21L |
|
Max traction |
5KN |
|
Max Lifting force |
4.6KN |
