Mini Order:250
deliver goods:Within 30 days
Send inquiry
| Technical Parameter | |||
| Axial clearance | C0 | Max Speed | 16,000 rpm |
| Bore diameter | 20mm | Operating temperature | -35℃～180℃ |
| Outer diameter | 47mm | Dynamic load rating | 12.84KN |
| Outer ring width | 14mm | Static load rating | 6.65KN |
| Inner ring width | 14mm | Inner ring material | GCr15 |
| Minimum assembly chamfer | 1mm | Outer ring material | GCr15 |
| Net weight | 0.107kg | Steel ball material | GCr15 |
| Packing | industrial package | Retainer material | SPCC |
| Packing number | 250pcs | Seal ring material | NBR |
