| Technical Parameter | |||
| Axial clearance | CM | Max Speed | 33,000 rpm |
| Bore diameter | 12mm | Operating temperature | -40℃～180℃ |
| Outer diameter | 28mm | Dynamic load rating | 5.4KN |
| Outer ring width | 8mm | Static load rating | 2.36KN |
| Inner ring width | 8mm | Inner ring material | GCr15 |
| Minimum assembly chamfer | 0.3mm | Outer ring material | GCr15 |
| Net weight | 0.0206kg | Steel ball material | GCr15 |
| Packing | industrial package | Retainer material | SPCC |
| Packing number | 1000pcs | Seal ring material | SPCC |
