Cooling CCD Camera MC21-N

Click image to view original image
Brand: MSHOT
型号: MC21-N
Price: Negotiable
Delivery: Shipment within 3 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2018-01-29 11:08
Hits: 326186
Company Detail
Professional-grade CCD microscope camera MC21-N is a newly released product independently developed by Mshot. It uses 2/3 inch CCD sensor SONY EXview HAD CCD, the effective pixels can be up to 1360(H)*1024(V). MC21-N is a high resolution digital color camera, its image is as good as Olympus DP71’s.

The bundled Mshot software is not only able to handle multi-aspect microscopic images, but also can measure the length, angle, area and other parameters of the objects, as well as print graphic reports.


  • 2/3 inch SONY ICX285AQ CCD sensor.
  • Effective pixels 1360(H)*1024(V).
  • Built-in 16M image cache.
  • Cooling temperature can reach to -20℃.
  • Support TWAIN and DirectShow simultaneous.
  • Compatible with Windows XP(32bit),Win7/8/10 (32bit,64bit)operating system.
  • Standard with MSHOT microscope digital imaging system.


  • High quality Sony CCD sensor make sure high clarity image.
  • Built-in 16 M image cache achieve full resolution (1.4 M) of 20 FPS preview at a high speed.
  • High effective pixels produce high quality images.
  • Deep cooling 20℃ effectively avoids thermal nosie.
  • Wide spectral response 380nm~1200mm provide high sensitivity.
  • Good compatible software fit to win10.

  • Fit to GFP,FISH,NIR,FRET weak fluorescent imaging, also DIC,phase contrastm, immunohistochemistry, bioluminescence and other imaging observation.
  • High quality of images show sharp details.
  • Lower thermo noise provides pure image background even long working time.
  • High speed preview offers fluent live image and video.
  • Multiple fuctions of software help users to achieve multiple purposes.

Application fields of MC21 CCD Camera:

Cooled CCD camera MC21-N can be used to do the analysis of ultra-weak fluorescence, chemiluminescence and flow cytometry, Microbiology and TB diagnostic . It is also widely used in fields of GFP,FISH,NIR,FRET imaging, bright field observation, DIC, living cell imaging, immunohistochemistry, bioluminescence and other imaging observation.

Spectrum response curve:

Parameters :

Model MC21 Camera type Color CCD Camera
Sensor Sony Pixel size 6.45um×6.45um
Sensor model ICX285AQ frame rate 15fps@ 1360*1024
Sensor size 2/3-inch (4:3) Shutter type Electronic shutter
Effective resolution Size 8.8mm (H) X 6.6mm (V ) diagonal 11mm Exposure control Automatic/manual
Effective pixels 1360H x 1024V(1.4MP) Dynamic range 67dB
A/D conversion(color depth) 12bit Data connector USB2.0(480Mbit/sec)
Scanning mode Progressive scanning Supporting connector SDK
Spectrum response 400nm~1200nm Camera connector Standard C-mount
Readout noise 4LSB Working temperature -30℃~+70℃
G sensitivity 1300mv Working power(current) DC 5V±5%
Cooling semiconductor refrigeration, - 28C°  at ambient temperature Operating system Windows2000、XP、Vista、Windows7 32bit/64bit
Controller  Image size, image acquiring, exposure time, GAMMA, contrast ratio, brightness, RGB gain, saturation Applications Weak fluorescent, chemiluminescence, bioluminescence, flow cytometry, bright and dark field observation, imaging of GFP, FISH, NIR, FRET, DIC, and live cell, IHC, infrared observation.
