1.Made by bauxite clinker and binder through Crushing,Mixing,Shaping,Drying and high temperature Sintering.
2.Al2O3 content is 48%-80%.
3.Main mineral components are corundum and mullite phases.
4.Refractoriness is usually above 1770°C,refractoriness under load is 1420-1550°C.It is a neutral refractory material so that it enjoys excellent resistance to acid and alkali corrosion.
5.Working temperature:1350°C -1650°C.
What is the Technique Data of our high alumina refractory brick?
|
Item |
Index |
||||
|
International code name |
SK35 |
SK36 |
SK37 |
SK38 |
SK40 |
|
Al2O3 % |
≥48 |
≥55 |
≥65 |
≥75 |
≥80 |
|
Fe2O3 % |
≤2 |
≤2 |
≤2 |
≤2 |
≤2 |
|
Refractoriness °C |
≥1750 |
≥1770 |
≥1790 |
≥1790 |
≥1790 |
|
Apparent porosity % |
≤22 |
≤22 |
≤23 |
≤23 |
≤21 |
|
Cold crushing strength Mpa |
≥39 |
≥44 |
≥49 |
≥54 |
≥65 |
|
Refractoriness under load(0.2MPa) °C |
≥1420 |
≥1470 |
≥1500 |
≥1520 |
≥1530 |
|
Reheating Linear Change (1500°C 2h) % |
+0.1~ -0.4 *1450°C |
+0.1~ -0.4 |
+0.1~ -0.4 |
+0.1~ -0.4 |
+0.1~ -0.4 |
What is the Feature of Our high alumina refractory brick?
1.High-temperature endurable;
2.Good thermal shock resistance;
3.High cold crushing strength;
4.Good resistance to abrasion and corrosion;
5.Good thermal spalling resistance;
6.High mechanical strength;
7.Good volume stability at high temperature;
What is the Applications of our high alumina refractory brick?
|
Iron & steel making industry |
Blast furnace,hot blast furnace(stove),pellet shaft furnace,hot metal ladle,steel ladle,tundish,heating furnace,soaking pit furnace,heat treatment furnace,refining furnace,reheating furnace,metal mixter furnace,annealing furnace,cupola furnace,electric arc furnace,induction furnace,AOD furnace,VOD furnace,etc thermal technology equipment . |
|
Non-ferrous metal industry |
Smelting furnace,refining furnace,reverberatory furnace,converter furnace, |
|
Building materials industry |
Cement kiln,glass kiln,ceramic kiln,lime kilns,kiln car,tunnel kiln |
|
Energy & Incineration |
Coke oven,general boiler,power,generation,boiler,circulating fluidized bed boiler,electric furnace,carbon roasting furnace,waste incinerators |
|
Others |
Petrochemical industry furnace |
What is the Shapes &Sizes of our high alumina refractory brick?
|
Straight |
Split |
Arch |
Wedge |
Tile |
Ohter Shape |
|
|
L×W×H(mm) |
||||||
|
Have in Stock |
230×114×65 230×114×75 230×57×65 |
230×114×32 230×114×40 |
230×114×65/45 230×114×65/55 |
|||
|
NO in stock |
230×114×25 230×114×50 |
230×114×75/45 230×114×75/55 230×114×75/65 |
230×230×38 230×230×50 230×230×65 230×230×75 |
Key brick,Skew brick, Soap,Checker,Neck, Taper, |
||
|
We also can make brick according to customers’drawing and requirements. |
||||||
