Features:
1.Self-priming design (require initial priming to operate)
2.Suitable for sea water transfer, irrigation, garden, mining and civil engineering
3.High quality PA66 plastic pump housing and impeller
4.High quality ceramic plunger, silicon carbide water seal
5.Low oil consumption, low noise
6.Powered by advanced YARMAX engine, reliable performance, easy start
| Model | YMDP50C | YMDP50M (mud pump) |
| Fuel Tank | 3.5L | 3.5L |
| Start system | Manual & Electric | Manual & Electric |
| Type | centrifugal pump | centrifugal pump |
| Inlet | 2"(50mm) | 3"(80mm) |
| Outlet | 2"(50mm) | 3"(80mm) |
| Max.head | 33m | 25m |
| Max.Flow | 34 m3/h | 57 m3/h |
| Pump body | PA66 Plastic | PA66 Plastic |
| Impeller | PA66 Plastic | PA66 Plastic |
| Engine type | Forced air cooled,4-stroke Diesel engine | Forced air cooled,4-stroke Diesel engine |
| Engine Model | 178F | 178F |
| Displacement | 296cc | 296cc |
