| Pump Model: | 1.5" LC40ZB60-4.5Q | 1.5"LC40ZB80-4.5Q | 2" LC50ZB60-4.5Q | 2" LC50ZB60-4.9Q |
| Engine Model | G200F | G200F | G200F | LC178F/D350F |
| Displacement | 196 cc | 196 cc | 196 cc | 349 cc |
| Bore×Stroke | 68mm×54mm | 68mm×54mm | 68mm×54mm | 78mm×73mm |
| Compression ratio | 8.5∶1 | 8.5∶1 | 8.5∶1 | 21∶1 |
| Net power | 4.1 kW/3600rpm | 4.1 kW/3600rpm | 4.1 kW/3600rpm | 4.9kW/3600rpm |
| Rated speed | 3600r/min | 3600r/min | 3600r/min | 3600r/min |
| Oil capacity | 0.6 L | 0.6 L | 0.6 L | 1.1 L |
| Fuel tank capcity | 3.6 L | 3.6 L | 3.6 L | 3.5 L |
| Pump type | Centrifugal,self priming | |||
| Dia.of discharge port | 40 mm | 40 mm | 50 mm | 50 mm |
| Dia.of suction port | 40 mm | 40 mm | 50 mm | 50 mm |
| Max suction | 6 m | 6 m | 6 m | 6 m |
| Max lift | 60m | 80m | 60m | 60m |
| Max delivery voulme | 25m3/hr | 13m3/hr | 30m3/hr | 30 m3/hr |
| Dimension | 435×380×390 | 435×380×390 | 520×415×460 | 570×490×550 |
| Net weight | 25.5 kg | 26.5 kg | 30.5 kg | 55 kg |
