Low Fuel consumption
With air-cooled diesel engine, make sure low fuel consumption
Portable design
New light weight and compact design make it easy and safe to move.
Convenient Maintenance
Aluminum self-priming pump, maintenance free; open design, easy leads to the engine.
Reliable and durable
Safe and reliable engine with enhanced pump cover structure assure the pump durable service.
Head high and less self-priming time
Strong engine and vortex impeller design, good sealing, greatly promote head of delivery, and less self-priming time
Model | KDP40HL/HLE | KDP50HL/HLE | KDP50B/L/LE | KDP80B/L/LE | KDP100B/L/LE |
Suction / Discharge Port Diameter[mm] | 40 ( 1.5") | 50 ( 2") | 50( 2") | 80( 3") | 100( 4") |
Cont. Capacity[m³/h] | 12 | 18 | 22 | 35 | 40 |
Cont. Head[M] | 42 | 45 | 15 | 17 | 19 |
Self-priming Time[s/4m] | 120 | 180 | 70 | 120 | 180 |
Max.Suction Head[M] | 6.0 | 6.0 | 7 | 7.0 | 7 |
Fuel Tank Capacity[L] | B: small fuel tank ( 5.5L) L: large fuel tank( 12.5L) | ||||
Engine Type | KD178F/FE | KD186FA/FAE | KD170F/FE | KD178F/FE | KD186FA/FAE |
Starting System | F: Recoil starter E: electric start | ||||
Engine Type | 1-Cylinder ,4-Stroke ,Air-cooled, Veritical | ||||
Broke * Stroke[mm] | 78*62 | 86*72 | 70*55 | 78 * 62 | 86*72 |
Displacement[L] | 0.296 | 0.418 | 0.211 | 0.296 | 0.418 |
Compression Ratio | 20:01 | 19.5:1 | 20:01 | 20:01 | 19.5:1 |
Rated Rotation Speed [rpm] | 3600 | 3600 | 3600 | 3600 | 3600 |
Rated Power[Kw] | 4.0 | 6.6 | 2.8 | 4.0 | 6.6 |
Lube[L] | 1.1 | 1.65 | 0.75 | 1.1 | 1.65 |
Fuel Type | 0#(summer), -10#(winter) Diesel oil | ||||
Lube | SAE10W30 ( above CD grade ) | ||||
Overall Diemension [mm]( L*W*H) | 570*465*670 | 655*480*720 | 490 * 410 * 520 | 560*455*550 | 650*470*700 |
N.W[Kg] | 47 | 67 | 41 | 49 | 69 |
