| Model: | 1" LC25ZB36-1.2Q | 1.5" LC40ZB21-1.2Q | 2" LC50ZB28-4.2Q | 2" LC50ZB30-4.5Q | 3" LC80ZB30-4.2Q | 3" LC80ZB30-4.9C | 3" LC80ZB35-4.5Q | 4" LC100ZB30-5.3Q | 4" LC100ZB30-4.9C |
| Engine Model | LC152F | LC152F | LC165F | G200F | LC170F | LC178F/D350F | G200F | LC175F | LC178F |
| Displacement | 97 cc | 97 cc | 182 cc | 196 cc | 212 cc | 349 cc | 196 cc | 265cc | 349cc |
| Bore×Stroke | 52mm×46mm | 52mm×46mm | 65mm×55mm | 68mm×54mm | 70mm×55mm | 78mm×73mm | 68mm×54mm | 75mm×60mm | 78mm×73mm |
| Compression ratio | 5.6∶1 | 5.6∶1 | 8.5∶1 | 8.5∶1 | 8.5∶1 | 21∶1 | 8.5∶1 | 8.2:1 | 21:01 |
| Net power | 1.2 kW/3600rpm | 1.2 kW/3600rpm | 4.0 kW/3600rpm | 4.1 kW/3600rpm | 4.4kW/3600rpm | 4.9kW/3600rpm | 4.1 kW/3600rpm | 5.3kW/3600rpm | 4.9kW/3600rpm |
| Rated speed | 4000r/min | 4000r/min | 3600r/min | 3600r/min | 3600r/min | 3600r/min | 3600r/min | 3600r/min | 3600r/min |
| Oil capacity | 0.45 L | 0.45 L | 0.6L | 0.6L | 0.6L | 1.1 L | 0.6L | 0.95 L | 1.1 L |
| Fuel tank capcity | 1.4 L | 1.4 L | 3L | 3.6 L | 3L | 3.5 L | 3.6 L | 4.6 L | 15L |
| Pump type | Centrifugal,self priming | ||||||||
| Dia.of discharge port | 25 mm | 40 mm | 50 mm | 50 mm | 80 mm | 80 mm | 80 mm | 100mm | 100mm |
| Dia.of suction port | 25mm | 40 mm | 50 mm | 50 mm | 80 mm | 80 mm | 80 mm | 100mm | 100mm |
| Max suction | 6 m | 6 m | 6 m | 6 m | 6 m | 6 m | 6 m | 6 m | 4 m |
| Max lift | 36 m | 21 m | 28 m | 30 m | 30 m | 30 m | 35m | 30 m | 24m |
| Max delivery voulme | 11 m3/hr | 12 m3/hr | 30 m3/hr | 30 m3/hr | 60m3/h | 60m3/h | 60m3/h | 97 m3/hr | 70 m3/hr |
| Dimension | 380×300×370 | 345×305×410 | 550×430×390 | 550×430×390 | 550×430×470 | 570×490×550 | 550×430×470 | 635×515×555 | 640×585×696 |
| Net weight | 13kg | 13 kg | 28 kg | 26kg | 31 kg | 52.5 kg | 29 kg | 47 kg | 76 kg |
