350W/370W co2 laser tube E350 Combined Beam Laser

Click image to view original image
Brand: JKLaserECO2
Price: 7900.00USD/piece
Min.Order: 1 piece
Supply 500 piece
Delivery: Shipment within 7 days since the date of payment
Address: China
Valid until: 2020-01-15 [Expired]
Updated on: 2018-04-26 16:16
Hits: 77734
Company Detail


Details


Laser specifications                Combined Beam Laser

Model         E350

Output Power( Rated Power/Max Power)(W)    350W/370W

"N" Type                      Waist located the output coupler

Beam Waist(2W.)(mm)                     5.9

Beam Divergence(mrad full angle)           2.6

B" Type                     Waist located outside the output coupler

Beam Waist(2W.)(mm)                     4.8

Beam Divergence(mrad full angle)           3.1

Pointing Stability(mrad)                  less than 0.1

Typical Power Stablilty(±% after warm up)     5

Polarisation              Random polarization or linear polarization

Maximum Strike Voltage(KV)                40

Rated Operating Current-Absolute max.(mA)    35 go to38

Dynamic Range                   Negative high voltage

Electrical Requirements                  6compare to1

Single Phase 110V-60Hz(A)                 14

230V-50Hz(A)                          8

Water cooling (W)                       1400

Dia(mm)                              80

L(mm)                              2179

W(mm)                               206

H(mm)                               166

Weight(kg)                            26

Wrranty                             12Months

Prics($)                            7900

Economy Type ELC Series Advantages

GIS UK original technology for Catalytic, GIS original formula for co2 gas, PERFECT LASER SPOT, Negative High Voltage Structure, More Stable and longlife ,  Excellent beam profile at all power levels, High Stability outpit,12Months lifetime, High vacuum technology for longlife time, Laser  tube and combined laser beam system as option ,Easy intergration  ,HV power supply HV, Algnment beam option, Diffusion colled design

2018 NEW Economy Type Laser ELC Series  Negative High Voltages Type Combined Beam Laser

Model

rated power(w)

Max Power(w)

Lengthmm)

W/H(mm)

Catalyst

Warranty

Price($)

E200

200W

200W~240W

1737

206*166

YES

12 Month

$4450

E260

260W

260W~300W

1848

206*166

YES

12 Month

$5050

E300

300W

300W~320W

1934

206*166

YES

12 Month

$6350

E350

350W

350W~380W

2179

206*166

YES

12 Month

$7900
