Fully Automatic Box type bag making &packaging machine
Technical Features:
1. This machine integrates the functions of bag-making, filling, sealing, printing, punching and counting. Has automatic film position control function, both the horizontal sealing and film pull mechanism adopts servo motor for transmission which guarantees the high efficiency of the machine.
2. The side seal is an independent mechanism and has an independent film position control system in the forming and side sealing process, which guarantees the stability of its side sealing and forming mechanism.
3. All of Control components adopt well-known international brands with reliable performance. The operator can adjust operation parameter on the touch screen.
4. Can make multiple types of bag such as four-side-sealed box bag, gusset bag, pillow bag, etc.
5. Can make the type of bag that needs to be added with vent valve according to material requirements.
Model |
External Dimensions (L×W×H)mm |
Type of Bag |
Bag Size(L×W)mm |
Packaging Capacity bags/min |
Reel Inner Diameter |
Max Reel Outer Diameter |
Compressed Air Requirement |
Power Supply |
MAC5000A5 |
2455×1230×1660 |
Pillow bag Box bag Punching bag |
Front Width:50~190 Side Width:35~90 Width of Side Seal:5~8 Bag Length Range:100~420 Max Width of Film:520 |
8~45 |
Φ75mm |
Φ450mm |
0.6MPa 350L/min |
380V 50~60HZ 3KW |
MAC7300A5 |
2550×1420×1930 |
Front Width:60~260 Side Width:45~120 Width of Side Seal:5~10 Bag Length Range:100~460 Max Width of Film:730 |
2~45 |
Φ75mm |
Φ450mm |
0.6MPa 350L/min |
380V 50~60HZ 3KW |
