Sweet potato starch plant construction for you

This sweet potato starch plant additional benefits:

1. Sweet potato seedlings and the skin residue after cleaning can make alcohol.

2. Protein water produced in the production process is extracted by the protein extractor can produce protein powder.

3. The discharged sweet potato residue can make feed after dewatering and further drying by DOING latest dewatering equipment.

Sweet Potato Starch Processing includes 11 machines: Dry Sieve，Paddle Washing, Cutting，Rasper，Centrifuge Sieve，Fine Fiber Sieve，Hydrocyclone Station，Vacuum Filter，Flash Dryer，Starch Sieve，Packing machine.



Detailed sweet potato starch processing plant information on the following:

(1) Washing Section: two accepts are included：Dry Sieve and Paddle Washing Machine. Dry sieve has the ability to avoid sewage disposal. According to multiple spiral operation, Paddle Washing Machine can remove silts and impurities from the surface of sweet potato.



(2) Crushing Section: sweet potato starch plant crushing section includes Cutting Machine and Rasper. Cutting Machine can cut sweet potato for primary crushing; Rasper is best for filing and fragmentation, so that the crushing rate will be higher. The advantage of it is to reduce the amount of work that next section needs to do.



(3) Screening Section: a. Centrifuge Sieve is stainless steel, easy for installation and maintenance.（high efficiency of starch sieving, good technical index）.

b. Fine Fiber Sieve →Mainly used for the removal of fine fiber in crude starch, higher throughput, low energy consumption and good effect of starch sieving.



(4) Concentrating Sections in sweet potato starch plant:

a.  Hydrocyclone Station can remove fiber, protein and cell to further process starch milk. The hydrocyclone pipe made of strengthened nylon.

b. Vacuum Filter: It is a solid-liquid separation machine which is formed by vacuum pressure and vacuum filtration. It is the negative pressure formed at the outlet of filtrate as a driving force for filtration. The basic principle of vacuum dehydrator for starch making is that under the action of vacuum negative degree(0.04-0.08MPa), the liquid in suspension is withdrawn through filter cloth, while solid particles are withheld.

(5)Drying Section of sweet potato starch production plant: Flash dryer is able to reduce the loss of starch depends on negative pressure system and guarantee the high standards of final project.

(6) Sieving Section: The function of starch sieve: classification the starch in accordance with the different mesh.

(7)Packing Section: Various spouts to meet different needs

The whole sweet potato starch processing equipment is comprised of five major sections: Washing & Crushing Sections, Screening Sections, Concentrating Sections, Drying Section and Packing Section. DOING has its own factory and entire sweet potato starch processing line, so we can offer you the best service, production and competitive price of sweet potato starch processing.
