The Tapioca starch production machines is a rising industrial project in Nigeria, Libieria,Ghana, Thailand,
etc. And Nigeria is one of the courtry which has plenty cassavas, and we
have many customers in Nigeria, also have installed some tapioca starch processing plant in Nigeria and surrounding countries in Africa.
So in order to fulfill the demanding enquiry from costumers and provide first class after-sale service, judge from the international market, Henan Doing Company decide to set up the branch office in Nigeria in 2018, and sent out our senior sales person to the local space to develop our business of tapioca starch production machines to match up with the developing work.
And till now, Henan Doing Company has invested large sum of money to do business of advertising in local newspaper and websites, inviting neighboring countries come to visit our office and the Tapioca starch production machines we have installed, which has greatly help us increase exposure in the surrounding countries and also lay out a foundation for future business development and expand and service offer.
-
-
-
- To extract starch from cassava, first you must crush the cassava to make the starch free from cassava pieces, then we can get cassava starch solution, next washing and sieveing the starch solution to get pure starch solution, then process the starch solution to get final starch. The total cassava starch production process is cassava cleaning-cassava crushing-seperating-concentration-refining-dewatering-drying. Extraction starch from cassava section include crushing, seperating and concentration.
- Especially in the cassava crushing section, adopt Doing Company newest design rasper to process, fully destroy the cassava cells, free starch from cassava pieces entirely. Combined with Doing Company centrifugal sieve, the extraction rate can be 94%-95%, it is the best production technology of starch extraction from cassava.
Cassava starch is a kind of white powder of tapioca that is dehydrated and dried after starch extraction. It is widely used in food industry and non-food industry. Cassava starch production is a very promising market. Doing company mainly engaged in the design, processing and manufacturing of the starch equipment, and make installation and commissioning for the supporting projects.
Cassava starch production line process:
Technical process:
Fresh
cassava - Cassava cleaning and washing - Grinding - Starch extraction -
Filtering and desanding - Starch concentration and purification -
Dewatering - Drying
Machine order:
Dry sieve - Paddle washer -
Cutting machine - Rasper - Centrifuge sieve - Fine fiber sieve - Disc
separator - Hydrocyclone - Vacuum filter - Flash dryer
Main equipments and its function in this cassava starch production line:
1) Cleaning parts of cassava starch production line:
Dry
sieve: Widely used in impurities pre-removal for starch production.
It's used to remove dirt, sand, small stones, weeds and other impurities
that are attached on the surface of potato, sweet potato and cassavas.
|
|
|
Paddle
washer: Mainly used to wash the raw materials. Adopted countercurrent
washing principle. By the effect of paddle pushing, the raw material
flows in the converse direction against water currently, which makes
washing completely and eliminate sand and mud at most.
2) Crushing parts of cassava starch production line:
Cutting machine: Its main function is cut cassavas into small pieces, 3-5cm, for further processing.
Rasper: Break the materials, crush cassavas into slurry, release starch particles from cell, with high starch dissociation rate.
3) Starch extraction of cassava starch production line:
Centrifuge
sieve: Used for the extraction of starch from the materials, remove
fiber from starch slurry, high starch extraction rate.
4) Starch filtering and desanding of cassava starch production line:
Fine
fiber sieve: It is a machine mainly for separating small particles of
fiber from starch slurry. This process is achieved by gravity of the
slurry and screen mesh inside the drum.
5) Starch concentration and purification of cassava starch production line:
Disc
separator: It is widely used in processing of starch to separate
protein and cell liquid out of slurry, with high separating factor.
Hydrocyclone:
It is designed to get rid of related substances such as fiber and
protein in the starch milk. For the starch's washing, concentration and
purification.
Usually suggest this two machine used in combination, make the production high efficiency and high quality.
6) Drying system of cassava starch production line:
Vacuum filter: Widely used for the starch dewatering, final starch water content is 38%-42%.
Flash
dryer: This is the last step for tapioca starch production. It adopts
low temperature drying system, which will prevent starch gelatinization.
Final starch water content is 12%-14%.
Above all, its the complete cassava starch production line.
-
