Product overview of DZSF linear vibrating screen
DZSF series linear vibrating screen is called linear screen for short, it is a kind of universal vibration screening equipment driven by double vibration motor. Equipped with two vibration motors, synchronous reverse rotation, the eccentric block to produce the exciting force in the direction parallel to the motor axis force offset each other, and in a plane perpendicular to the direction of the motor shaft of the force in the eccentric block to reach the maximum, so the motion track of the vibrating screen is a straight line. Two, the motor shaft has a dip angle on the relative sieve surface. Under the action of the resultant force of the exciting force and the gravity of the material, the material is thrown on the screen surface to make straight motion in a straight line, so as to achieve the purpose of screening and grading materials.
DZSF series linear vibrating screen is suitable for sieving of all kinds of dry powder materials with a particle size of 0.074-5mm and less than 7% water content. The maximum granularity is generally less than 10mm. Can also be filtered liquid screening operations of this series of vibrating screen, used for sewage treatment, can also be used for larger particles of coal material sieving, in large material treatment, screen thickness must be thicker, the motor power required to increase facelift punching sieve as screen. In detail, please consult our technical staff.
Main features of DZSF linear vibrating screen
The DZSF series linear vibrating screen has the advantages of small volume, simple and reasonable structure, high screening accuracy, totally closed, pollution-free, low noise, low energy consumption, convenient maintenance, simple maintenance and long service life of screen. It can be used for single storey or multi-storey, up to five levels. The screen frame is generally made of wooden structure. If the sieve hole is large and the yield is high, the screen frame can be made into steel structure. If the corrosive material is screened, the contact part with the material is made of stainless steel. The installation of the motor can be divided into the lower vibration and the side vibration. The installation of the damper can be divided into the seat type and the hanging type. In addition, our company can also carry out special design and manufacture according to the needs of the user.
DZSF linear vibrating screen suitable for Industry
DZSF linear vibrating screen is suitable for 0.74-10mm, water cut less than 7%, no viscous material of any dry material sieving. It is mainly used for screening dry powder, fine grained or fine powder materials in abrasives and abrasives raw materials, chemical industry, plastics, medicine, resin powder, ceramic raw materials, metallurgy, building materials, grain, fertilizer and other industries.
This machine is mainly composed of screen box, screen frame, screen, vibrating motor, motor pedestal, the damping spring bracket, etc.. Product structure of linear vibrating screen and functional description of various parts
1, sieve box: a number of different thickness of the steel plate made of welding, with a certain strength and stiffness, is the main component of the screening machine.
2, screen frame: wood made of pine or small deformation of wood, mainly used to keep the screen smooth and reach normal screening.
3, screen: there are several kinds of screen mesh, such as low carbon steel, brass, bronze, stainless steel wire and so on.
4. The vibration motor (use and repair methods are detailed in the instructions for using the vibration motor).
5 motor pedestal: the vibration motor is installed before using the connecting screw must be tightened, especially the new machine three days before trial, must be repeated fastening to prevent loosening of the accident.
6, damping spring: prevent the vibration from passing to the ground, and support all the weight of the sieve box. When installation, the spring must be perpendicular to the ground.
7, support: it consists of four pillars and two channel steel, supporting the screen box. When installing, the pillar must be perpendicular to the ground, and the channel steel under the two pillars should be parallel.
