Customized Pneumatic & Electrical & Hydraulic Rotary Joint Rotary Union

Click image to view original image
Brand: Victory-Way
Price: 1.00USD/Hybrid Sli
Min.Order: 1 Hybrid Sli
Supply
Delivery: Shipment within 8 days since the date of payment
Address: China
Valid until: 2020-08-26 [Expired]
Updated on: 2019-03-08 09:13
Hits: 22444
Company Detail


Details
Technical spec:
Speed: 100 Rpm;
Operate temperature:-30~90℃
protect degree:IP54
Housing: Al alloy

Part A:(Electornic Slip Rings)
Channels: 12 rings(for signal);
Operation Voltage: 0~240VAC/DC;
Current : 2A/Ring;
Contact material: Precious metal;
Electric Nosice:Max.40m Ω;
Dielectric strength: 500VAC@50Hz,60s;
Insulation resistance:500MΩ @600VDC;

Part B:(Rotary Joint)
Channels:2 Ways
Pressure:1.6Mpa Max

Media:compressed air/ vacuum


Our products are widely used in: Security, Factory Automation, Electric Instrumentation, Medical, Aerospace, Marine,Civil and Military Fields.Such as: Crane, Giant Wheel, Cotton Picker, Medical Equipment, Detector,Rotary Tables,Robots,Strander, Webcam, Automatic Revolving Door,Exhibit / Display Equipment, Food Manufacturing Machine,Packaging Machine,Amusement Equipment, Irrigation Machine,Heated Rollers etc.

More product information welcome to visit our website www.victory-way.com.
