Product description:
The automatic paper embossing machine with the functions: automatic feeder & auto collecting picker. Full automatic control in processing, adopt frequency governor, automatic hydraulic system and pneumatic blade, it is characterized by controllable speed, double-sheet control, automatic counting, etc. Its average can range from 3000~5000pc/h. It is applied to embossing the sheet surfaces of batches like packing products, playing cards, gift cards, golden and silver card paper, etc.
Optional collector:
-Auto vibrating collector
-Manual collecting table
Main technical parameter:
Model: YW-720E
Max embossing speed: 80 m/min
Max embossing width: 680mm
Paper range: >160 g/m2
Operation pressure: 2-10 Mpa
Main motor pressure: 14 kw
Vacuum pressure: 0.06 Mpa
Air source pressure: 1.8-1.0 Mpa
Overall dimension(LxWxH): 4800x1500x1800 mm
Machine weight: 2800 kgs
Model: YW-920E
Max embossing speed: 80 m/min
Max embossing width: 880mm
Paper range: >160 g/m2
Operation pressure: 2-10 Mpa
Main motor pressure: 15 kw
Vacuum pressure: 0.06 Mpa
Air source pressure: 1.8-1.0 Mpa
Overall dimension(LxWxH): 4800x1700x1800 mm
Machine weight: 3500 kgs
Model: YW-1150E
Max embossing speed: 80m/min
Max embossing width: 1000mm
Paper range: >160 g/m2
Operation pressure: 2-10 Mpa
Main motor pressure: 16 kw
Vacuum pressure: 0.06 Mpa
Air source pressure: 1.8-1.0 Mpa
Overall dimension(LxWxH): 4800x1800x1800 mm
Machine weight: 4200kgs
Model: YW-1300E
Max embossing speed: 80 m/min
Max embossing width: 1180 mm
Paper range: >160 g/m2
Operation pressure: 2-10 Mpa
Main motor pressure: 18 kw
Vacuum pressure: 0.06 Mpa
Air source pressure: 1.8-1.0 Mpa
Overall dimension(LxWxH): 4800x2000x1800 mm
Machine weight: 5000kgs
