Automatic Chopsticks Pocket Making Machine MODEL HP-250C -iseef.com

Click image to view original image
Price: 10.00USD/set
Min.Order: 1 set
Supply 1 set
Delivery: Shipment within 25 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2018-08-09 15:36
Hits: 44356
Buy
Company Detail


Details

Structure features:

Automatic envelope maker Model HP-250 suitable for producing 1-6# Chinese style envelope, glasses bag, red pocket and very small paper bag such as chopstick bag, medicine bag.


Air suction type reliable bottom paper extracting structure is available to supply paper constantly.

Completed with air suction roller and barrier system, it is available to accomplish double fold correctly.

Rotary paste supplying is suitable to convert envelopes swiftly and stick paper bags.

Electronic counter may control finished products by group for easy use of package.


Technical parameter:

Model: HP-250C

Max. working velocity: 12000pc/h

Applicable paper ration: 50-157gsm

Min. dimensions of an envelope: 28*50mm

Max. dimensions of an envelope: 118*290mm

Motor power: 1.5kw

Air pump power: 3.0kw

Machine weight: 800kgs

Machine Size: 1800*900*1220mm
