Micron |
1μm, 5μm, 10μm, 15μm , 20μm, 40μm, 70μm |
||||
|
OD |
6" (152mm) |
||||
|
Length |
40" |
||||
|
Maximum operating temperature |
Pleated Glass Fiber: 121℃ |
||||
|
Pleated Polypropylene: 82℃ |
|||||
|
Maximum operating differential pressure |
Pleated Glass Fiber: 3.44bar@121℃ |
||||
|
Pleated Polypropylene: 3.44bar@82℃ |
|||||
|
Suggestion pressure for filter replacement |
2.5Bar@20℃ |
||||
|
Suggestion Max. flow rate |
40" filter 70m3/h |
||||
|
Model |
Filter Media |
Support/Drainage |
End Caps |
Seals Material |
|
|
PP |
Deep Pleated Polypropylene |
Polypropylene |
Glass Fiber Reinforced Polypropylene |
NBR, EPDM, Viton |
|
|
GF |
Glass fiber/polyester |
Polyester |
Glass Fiber Reinforced Polypropylene |
||
