Superficial tissue may obscure part of the illumination light when deep surgery, thus forming partical shade in the surgical field. Petal model series set to deep illumination mode, the system automatically turns off the invalid LED light source and selectively automatic enhance effective led light brightness to repair shadow. Petal model series light use advanced technology, with unique performance and advantages, which can meet the various surgical lighting
Technical parameters:
Technical parameters MINGTAI LED720 MINGTAI LED520
Illuminance (lux) 160,000 120,000
Color Temperature (Kelvin) 4,300 4,300
Adjustable Color Temperature (Kelvin) (Optional) 3600-5600 3600-5600
Color Rendering Index (CRI) 96 96
Red Color Index (R9) 96 96
Light brightness control standard standard
Brightness control range 10-100% 10-100%
Temp rise (Surgeon head) (℃) 0.5 0.5
Temp rise (surgical field) (℃) 2 2
Effective Focusing Depth (cm) 60-150 60-150
Total Irradiance Ee (W/m2) 530 470
Radiant Power Ee/ Ec (mW/m2lux) 3.3 3.3
Lighting Spot Size (mm) 100-260 100-260
Bulb Type LED LED
Average Bulb Life (hours) 60,000 60,000
Bulb Quantity (main bulb+ auxiliary bulb) 140LEDS+420LEDS 84LEDS+252EDS
Depth of illumination L1+L2 (cm) 130 130
Power Consumption (W) 70 50
Height adjustment (cm) 118 118
Power Input 100-240VAC, 50/60Hz 100-240VAC, 50/60Hz
Product feature:
1. Petal model series light use advanced technology, with unique performance and advantages, which can meet the various surgical lighting
2. Unique lighting depth adjustable technology
Superficial tissue may obscure part of the illumination light when deep surgery, thus forming partical shade in the surgical field. Petal model series set to deep illumination mode, the system automatically turns off the invalid LED light source and selectively automatic enhance effective led light brightness to repair shadow
3. Long life lighting source
The lifetime of LED light source is 40 times than halogen bulb, reaching 60,000H, and each led bulb can be changed separately
4. Perfect cold light effect
LED don`t engender infrared ray, temperature rising in doctor`s head is less than 0.5℃, and low temperature rising in the surgical field can prevent body fluid`s losing during operation
5. Petal model series shadowless light appearance is open type design, which meet the aerodynamic principles, and it also can reduce the light head area which will block the purify air flow, so as to minimize the light air turbulence which will affect the purification effect
6. Optional adjustable color temperature technology
Petal model series (adjustable color temperature) surgery light consists of 4 different LED bulb, by adjusting the brightness of different colors, you can adjust the color temperature between 3000-6000K to meet the doctor habits. The color temperature also can be adjusted according to the blood support quantity to distinguish different tissues
Shandong Mingtai Medical Equipment Group Co., Ltd is established in 2000 year, supporting operating room and ICU medical equipment. Since company established, continue to develop, keep making progress, let people enjoy the health future with better quality and service. Mingtai products get ISO13485, ISO9001, CE & SFDA certification. Mingtai company have many Shadowless Lamp, Surgical Table, Icu Bed and Medical Bridge Pendant patents. Mingtai brand series Operating Light, Operating Table, Medical Pendant, Hospital Bed and air disinfection equipment meet different distributor and customer`s different requirement.
Looking for ideal Mobile Surgery Shadowless Light Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Shadowless Ot Light are quality guaranteed. We are China Origin Factory of Led Dental Surgical Light. If you have any question, please feel free to contact us.Product Categories : Operating Lamp > Mobile Wall Shadowless Lamp
