SPECIFICATIONS:
Design Features:
√ Ductile iron fully lined casing provides durability, strength and long service life.
√ Multi-stage high pressure operation to 750 psi.
√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime.
√ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs.
√ Large, open internal passages designed to maximize wear life and lower operating costs.
√ Thick elastomer and alloy liners provide superior corrosion resistance and maximum wear life.
√ Full flush gland, low flow, and dry running centrifugal seals reduce flush water usage minimizing pump operating costs.
Tobee® HH High Head Slurry Pumps Applications:
HH high head slurry pumps widely used for wet crushers, SAG mill discharge, ball mill discharge, rod mill discharge, Ni acid slurry, coarse sand, coarse tailings, phosphate matrix, minerals concentrate, heavy media, dredging, bottom/fly ash, lime grinding, oil sands, mineral sands, fine tailings, phosphoric acid, coal, flotation, sugar beets, process chemical, pulp and paper, FGD, waste water etc.
horizontal slurry pump
fertilizer injection pump
open impeller pump
waste slurry pump
cad drawing slurry pump
rubber impeller pump
mine pump
cement pump
slurry mud sand pump
chokeless pump
gold recovery pump
Email: Sales7@tobeepump.com
Web: www.tobeepump.com / www.slurrypumpsupply.com
Skype: liulynn66
Size: 1" to 6" Capacity: 16.2-1008m3/h Head: 12-118m Handing solids: 0-70mm Casing pressure: Max.750 psig Materials: Hyper chrome alloy etc.Tobee® HH High Head Slurry Pump lines were designed to produce high heads per stage at high pressures, Commonly used for long distance transport lines, the HH slurry pumps can often satisfy application duties with a single pump where others require multiple pumps in series.
Design Features:
√ Ductile iron fully lined casing provides durability, strength and long service life.
√ Multi-stage high pressure operation to 750 psi.
√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime.
√ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs.
√ Large, open internal passages designed to maximize wear life and lower operating costs.
√ Thick elastomer and alloy liners provide superior corrosion resistance and maximum wear life.
√ Full flush gland, low flow, and dry running centrifugal seals reduce flush water usage minimizing pump operating costs.
Tobee® HH High Head Slurry Pumps Applications:
HH high head slurry pumps widely used for wet crushers, SAG mill discharge, ball mill discharge, rod mill discharge, Ni acid slurry, coarse sand, coarse tailings, phosphate matrix, minerals concentrate, heavy media, dredging, bottom/fly ash, lime grinding, oil sands, mineral sands, fine tailings, phosphoric acid, coal, flotation, sugar beets, process chemical, pulp and paper, FGD, waste water etc.
