Electric Air Heater Heating for Poultry Houses

Click image to view original image
Place of Origin: China
Condition: New
Type: Air Heater
Price: 4000.00USD/Unit
Min.Order: 1 Unit
Supply 1000 Unit
Delivery: Shipment within 15 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2019-12-04 16:39
Hits: 64389
Buy
Company Detail


Details


     Poultry House Heating System



Description


Material of tank: 304 stainless steel,steel, carbon steel

Application: food industry,machinery,coal mine

Customization: acceptable

Pressure: MAX 0.6 Mpa

Thermal Efficiency: More than 95 percent

Optional: air fan , temperature controller

Max.temperature: 600 deg c

After-sales Service Provided: Overseas third-party support available

Warranty: one year

Industrial Air Duct Type Heater For Factory Warm

This heaters are mainly used for heating air through the duct. There are three types,

low temperature, middle temperature and high temperature. The outer stainless steel sheath

and construction can reduce the vibration of heating elements. There is a overheat protector

in the terminal box. Air pressure through the duct should not exceed 0.3KG/cm². Or else it is

better use recirculation duct heaters. Max temperature of low temperature duct heater is not

more than 160 C. Max temperature of middle temperature duct heater is not more than 260 C.

Max temperature of high temperature duct heater is not more than 600 C.

Application of SANHE Auto Electric Heating Mahinne

It can be widely used in heating greenhouse, henhouses, piggery, and the factory buildings and also used in drying wood, tea, medicine, and food etc.

Technical Parameters 30KW 50KW 80KW 120KW
Heat output power kcal/h 25000 kcal/h 40000 kcal/h 65000 kcal/h 100000 kcal/h
Heat efficiency ≥% ≥99% ≥99% ≥99% ≥99%
Fuel electricity electricity electricity electricity
Way of control auto auto auto auto
Air flow m³/h 8700 m³/h 14000 m³/h 17400 m³/h 20000 m³/h
Temperature rise °C 60-120 °C 60-120 °C 60-120 °C 60-120 °C
Power Source V/Hz 380V/50Hz 380V/50Hz 380V/50Hz 380V/50Hz
Electric power kw 32 Kw 52 Kw 82 Kw 123 Kw
Diameter of air outlet mm 400mm 400mm 400mm 400mm
Weight kg 500Kg 680Kg 890Kg 700Kg
Dimension
   length×width×height mm
1100×1100×1800 1400×1100×1800 1600×1100×1800 1800×1200×2200
Material of frame Galvanized +spray paint Galvanized +spray paint Galvanized +spray paint Galvanized +spray paint
Quality guarantee period One year warranty lifelong service One year warranty lifelong service One year warranty lifelong service One year warranty lifelong service


Features

1. During heating,air max temperature can reach 850 degree celsius,but the surface temperature of the sheath is just around 50 degree Celsius.

2. Heat efficient is more than 95%

3. Temperature raise rate:10 degree Celsius per second during working

4. The heating element is made of high temperature alloy with good mechanical character

5. Usage time:standard more than 10 years

6. Clean air,small volume

7. Made as client design,2KW~1000KW

8. After reached the max temperature,the working wattages can reduce to half.
