SHANDONG JINGYU STEEL is well-known for its extensive color selection for aluminum coil painted. We have over 35 stock paint colors. There are stock colors for every industry including the Sign & Graphics industry, the Transportation industry, and the Architectural & Roofing industry. SHANDONG JINGYU STEEL provides painted aluminum sheet in custom and corporate identity colors, and have the capabilities to color match if you need an exact paint match.
If you need a custom size, we can provide you with the widths and lengths you require. We have cut-to-length, slitting, blanking and shearing capabilities. We can also slit aluminum coil to the size you require for your project.
As painted aluminum specialists, we are able to provide various types of custom orders. If your project requires painted cold-rolled or galvalume, we provide those materials upon request, also provide alternative paint systems.
| Place of Origin | Shandong, China (Mainland) |
| Application | ACP. wall cladding. facades. roofs and canopies. ceilings. signboards. blind window. display platforms. electrical panels. etc. |
| Length | any length depands on the coil weight |
| Width | Standard width 1240 mm, 1270 MM. Special width 1000 mm. 1200 mm. 1240 mm, 1270 mm. 1520 mm. 1620 mm |
| Thickness | From 0.013 mm to 1 mm |
| Weight | 2.5 T/coil, 3.0 T/coil |
| Alloy Or Not | AA 1100. 3003. 3004. 3105. 5006. 5052. 3011. etc . |
| Grade | 1100, 3003, 3005, 3105, 8011 |
| Coating paint | PVDF, PE(Polyester), epoxy, polyamide, polyurethane. |
| Coating thickness | PE: >=16 micron , PVDF: >=25 micron |
| Temper | H 16, H 18. H 24. H 26. H 28 |
| Color | soid, metallic, high gloss, stone, timber, brush, mirror, sparkling, etc. RAL or by customer requirements. |
| Surface | Embossed, mill finish, coated |
| Coating Hardness (pencil resistance) | More than 2h |
| Impact Resistance | No peeling or cracking(50 kg/cm) |
| Coating Thickness | PE coating: more than 16 micron PVDF coating: more than 25 micron |
| Guarantee | PVDF 15 years/ PE 15 years no color fade. |
| Certification | SGS / CE / CTC / ISO 9001:2008 / ISO 14001:2004 / GB/T 1774-1999 |
| Diameter |
outer diameter : Standard dia 1200 mm Inner diameter : 150 mm. 405 mm. 500 mm. 505 mm. 510 mm |
You can choose the customized color you want and produce according to the RAL color. Here are some of the colors that our customers would normally choose:
Why SHANDONG JINGYU STEEL Decorative Prepainted Aluminum Coil
20+ years manufacture experience of color coated aluminium.
Our company is specialized in the production of color coated aluminum, color coated steel and hot dipped galvanized steel. Our company owns four local and overseas advanced production lines for color coated coils and two for hot dipped galvanized, with the capacity of 80,000 tons/year.
- 20+ years manufacture experience.
- Export to 20+ countries already.
- More than 1000 employees.
- Approved by SGS, ISO 9001, CTC, etc.
- Offer Free Sample.
Shandong Jingyu Plate Co., Ltd. is mainly engaged in color coated sheets (reticulated sheets, embossed sheets, anti-corrosion nano-insulation sheets, writing boards, household appliances sheets, fingerprint resistant sheets etc.), galvanized sheets, aluminized galvanized sheets, PVC sheets,sheets, strip boards, various export tile types.
Coating Process
We have our own Physical & Chemical Testing Center Lab to guarantee our product quality. Our test items & instrument fully meet international standards.
