Dimensions:
No. of Teeth: 9
Length: 77.5
Drive O.D.: 60
No. of Splines: 6
Pinion O.D.: 34.8
Pinion I.D.: 14.3
Rotation: CW
Application:
Alfa Romeo
30 - 32 - 35 - 40 (AR 8)
Fiat
131 D - 132 D, ARGENTA D, CAMPAGNOLA D, DUCATO D
Fiat Allis
450 - 480 - 500 - 550 - 580
780 - 850 - 880 - 1000
FE - FL - FR 7-9 - TL 5
TRATTORI SERIE 46/66
Fiat Iveco
DAILY
OM
GRINTA
Seat
131 D, Simit, S 60
OEM & CROSS REF. NO.:
Cargo
131109 132821
Fiat
79023774 79081045 7984505 9000862 9961781 9927793 9929081 9935731 9936772 9957707 9986112
Italacciai
SD077 SD125 SD128
Lester
17111 17126 18092 18093
Lucas Indiel
221833
Magneti - Marelli
72138901 72139001 72139007 72159801 72363401 72363402 72397101 72397106 85540151
Vis Nova
21-41-21 21-41-29 21-41-01 01-41-23 01-41-64 01-41-78
ZEN
1.01.0407.0 1.01.0601.0
Starter Drive feature:
Main materials: Cr20 steel
Cold extrusion process to both sleeve and pinion
CNC lathe turning keep the precision
Nitrocarburizing, hardness 55-62 HRC, carburizing thickness 0.8mm
Strong enough rollers and flat spring and perfect inner design for long life using and avoid of slip.
Grease feature: -40 to 180 temperature resistance
Durability test: not less than 30,000 cycles.
