MIA-600M high contrast metallurgical microscope

Model

MIA-600MB

MIA-600MBT

Optic

Infinite optical or finite optical system

Eyepiece

Wide field WF10X(¢20mm)

Head

30º inclined binocular

30º inclined trinocular(0:100)

Infinite LWD

metallurgical

plan objective

5X/NA0.15 ,WD=12mm,

10X/NA0.3,WD=16mm,

20X/NA0.4，WD=12mm,

50X/NA0.55，WD=9.2mm,

Epi-illumination

High brightness 10W LED light, brightness

adjustable wide voltage 110-240V

Nosepiece

Quadruple nosepiece or quintuple nosepiece

Stage

Double layer mechanical stage190x140mm.moving range 75X50mm

Optional

accessory

Eyepiece

Reticle WF10X（grid 0.1mm）

WF16X，WF20X

Infinite LWD

plan objective

40X/NA0.6,WD=2.9mm

60X/NA0.7,WD=2.9mm

80X/NA0.75,WD=2.73mm

100X/NA0.8(dry))WD=3.1mm

Finite LWD

plan objective

5X/NA0.12,WD=11mm

10X/NA0.25,WD=19mm

20X/NA0.4,WD=5.8mm

50X/NA0.75,WD=1.5mm

60X/NA0.7,WD=1mm

100Xdry /NA0.8, WD=1.15mm

Polarizing kits

Pull type polarizer and analyzer 360º rotatable

CCD interface

0.5X、1X
