Active Components AD623ARZ Electronic ComponentsSingle & Dual-Supply, Rail-to-Rail, Low Cost Instrum

Pictures:




Features and Benefits:



1.

Easy to use Rail-to-rail output swing Input voltage range extends 150 mV below ground (single supply)










Low power, 550 μA maximum quiescent current










Gain set with one external resistor Gain range: 1 to 1000 14-terminal, 6 mm 5.6 mm 2.2 mm, LCC package High accuracy










DC performance 0.10% gain error (G = 1) 0.35% gain error (G > 1) Noise: 35 nV/√Hz RTI noise at 1 kHz










Optimal dynamic specifications 800 kHz bandwidth (G = 1) 20 μs settling time to 0.01% (G = 10)
2.




Products details:



the AD623 is an integrated, single- or dual-supply instrumentation amplifier that delivers rail-to-rail output swing using supply voltages from 2.7 V to 12 V. the AD623 offers user flexibility by allowing single gain set resistor programming and by conforming to the 8-lead industry standard pinout configuration. with no external resistor, the AD623 is configured for unity gain (G = 1), and with an external resistor, the AD623 can be programmed for gains of up to 1000.

the accuracy of the AD623 is the result of increasing ac common-mode rejection ratio (CMRR) coincident with increasing gain. Line noise harmonics are rejected due to constant CMRR up to 200 Hz. the AD623 has a wide input common-mode range and amplifies signals with common-mode voltages as low as 150 mV below ground. the AD623 maintains optimal performance with dual and single polarity power supplies.



Application:

1.


Low power medical instrumentation

Transducer interfaces

Thermocouple amplifiers

Industrial process controls

Difference amplifiers

Low power data acquisition
