When various bacteria and viruses in water or air irradiate the area of UV light, ultraviolet rays penetrate the cell membrane and nucleus of the microorganism, destroying the molecular bond of the nucleic acid (DNA or RNA), losing its replication ability or inactivation and died, thus killing all bacteria and viruses in the water or air without using any chemical drugs. UV disinfection does not produce any pollutants.
Benefits
1. High efficient UV Light Sterilizer
Normally kill 99-99.99% bacteria within 1 to 2 seconds.
2. Broad spectrum
Ultraviolet Water Disinfection has broadest spectrum, can kill almost all bacteria and virus.
3. No secondary pollution
Do not add any chemical, so can not create secondary pollution to water and ambient environment,
and do not change any ingredient in water.
4. Safe and reliable to operate
Traditional disinfection technologies, such as chloride or ozone, which disinfection agent itself are
highly toxic and flammable material while 48 gpm uv light sterilizer has no such potential safety hazard.
5. Low maintenance fee
UV lamps occupies a small area; structure requirement is simple, so total investment is smaller.
Lower in operation, it costs only half than that chlorine disinfection in kiloton water treatment.
Model Power Diameter Length Flow rate
WUVA-004 4w 50.8mm 200mm 0.3GPM（0.07M³/Hr)
WUVA-006 6w 50.8mm 260mm 0.5GPM（0.1M³/Hr)
WUVA-012 12w 50.8mm 315mm 1.0GPM（0.2M³/Hr)
WUVA-016 16w 63.5mm 375mm 2.0GPM（0.4M³/Hr)
WUVA-025 25w 63.5mm 595mm 6.0GPM（1.4M³/Hr)
WUVA-030 30w 63.5mm 915mm 8.0GPM（1.8M³/Hr)
WUVA-035 35W 63.5mm 955mm 9.0GPM（2.0M³/Hr)
WUVA-040 40W 63.5mm 890mm 10.0GPM（2.3M³/Hr)
WUVA-055 55w 63.5mm 955mm 12.0GPM（2.7M³/Hr)
