Foot sensor device for electric tailgae lift system
Item No.: KMFS000
By installing a sensor at the rear of the vehicle and connecting it to the signal wire of the original car’s rear trunk, when the car is unlocked and the sensor senses that someone performs an unlocking action within a certain range, the tailgate will aut
What is foot sensor (kick activated) device?
By installing a sensor at the rear of the vehicle and connecting it to the signal wire of the original car’s rear trunk, when the car is unlocked and the sensor senses that someone performs an unlocking action within a certain range, it will automatically open or close the rear door.
Foot Sensor Device KaiMiao Accessory List:
|
Accessory Name |
Description |
|
Package Size: |
22.5*15.5cm |
|
Weight: |
0.36kg |
|
Wire harness A: |
1.8m |
|
Wire harness B: |
4m |
|
Tips: |
1 |
|
Wire clamp: |
1 |
|
Fuse: |
2 |
https://www.kmautospace.com/foot-sensor-p00425p1.html
Parameters:
|
Part |
Parameter |
Description |
|
ECU |
Size: |
66*36*26mm |
|
Weight: |
0.047kg |
|
|
Operating Voltage Range: |
DC8 ~ 20V |
|
|
Working Temperature Range: |
-30℃ ~ 75℃ |
|
|
Working Current: |
≤14mA |
|
|
Stand-by Current: |
≤7.28mA |
|
|
Power Reverse Connection Protection: |
YES |
|
|
Short Circuit Protection: |
YES |
|
|
Fuse Holder: |
3A |
|
|
Over Temperature Protection: |
95℃ |
|
|
Waterproof Level: |
IP67 |
|
|
Sensor |
Detection Method: |
Millimeter Wave |
|
Responding Speed: |
100uS |
|
|
Sensing Distance: |
5-15cm |
|
|
ACC System |
Detect ACC Power Consumption: |
Increase 2.28mA |
|
Detection of ACC Method: |
The same chip detects status |
|
|
ACC Detection Process: |
When ACC detects high power frequency, the host does not output; when there is no high power frequency, the host outputs. |
|
|
- |
Warranty: |
1 year |
