Standrd Deviation per 1km Double-Run Leveling	Optical Reading	±1.5mm
	Electronic Reading	±1.5mm
Electronic Reading System	Measuring Range	2.5m～100m
	Single Measuring Time	Approx.3second
	Min. Altitude Reading	0.2mm
	Min. Distance Reading	0.01m
Magnification		28×
Objective Aperture		40mm
Shortest Focusing Distance		0.5m
Resolution Power		4"
Setting Accuracy		±0.5"
Leveling Time		2"
Image of Telescope		Erect
Compensation Type		Magnetic Damping
Compensator Working Range		±15'
Field of View		1°30'
Multiplication Constant		100
Additive Constant		0
Sensitivity of Circular Level		8'/2mm
Display		LCD
Data Port(interface)		RS-232C
Data Memory		1000points
Power Supply		Rechargeable Battery(Ni-H):6v/1.3AH When the power is used out,DAL1528 or DAL1528R would be ordinary Auto-Levels!!
Operating Time		Approx.10hrs
Auto Power-Off		5 minutes later
Horizontal Outer Circle		360°/1°
Ambient Temperature		－20°C～＋50°C
Standard Accessories		Digital Staff Adjusting Pin,Desiccating Agent. Allen Wrench,Plumb Bob,User Manual</td> </tr> <tr> <td height="28" align="left" colspan="2">Recommended Tripod </td> <td colspan="3" align="left"> Please refer to "Surveying Tripods"</td> </tr> <tr> <td height="28" align="left" colspan="2">Recommended Staff </td> <td colspan="3" align="left"> Please refer to "Staff&Rods":Al.Digital Staff(ADS)</td> </tr> <tr> <td height="28" align="left" colspan="2">Packing Details </td> <td colspan="3" align="left"> <textarea name="PD" disabled="disabled" cols="40" rows="5" id="PD">1pc per Carton;<br>6kgs per Carton;<br> Size:0.06CBM(50cm×30cm×40cm) </td> </tr> <tr> <td height="28" align="left" colspan="2">Note</td> <td colspan="3" align="left"> Any updating would be subject to change without prior notice!!</td> </tr> </table></div> <div id="comment_div" style="display:;"> <div class="left_head"><span class="f_r"><a href="http://www.chinaexporter.com/comment/index.php?mid=5&itemid=2351">Total: <span id="comment_count">0</span> [Show All]</a> </span>Related Reviews</div> <div class="c_b" id="comment_main"><div></div></div> </div> <script type="text/javascript" src="http://www.chinaexporter.com/file/script/comment.js"></script> </div> </div> <div class="m"> <div class="b10"> </div> <div class="box_head"><div><span class="f_r"><a href="http://geomaster.chinaexporter.com/sell/">More »</a></span><strong>Our Others Products</strong></div></div> <div class="box_body"> <div class="thumb" style="padding:10px;"> <table width="100%"> <tr align="center"><td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=1805"><img src="http://www.chinaexporter.com/file/upload/geomaster/200854125859gf-wf08bB.jpg" width="80" height="80" alt="GF-WF08B3"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=1805" title="GF-WF08B3">GF-WF08B3</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=2056"><img src="http://www.chinaexporter.com/file/upload/geomaster/200711201393al13gn2-b.jpg" width="80" height="80" alt="Prism Adaptor: AL13GN2-B"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=2056" title="Prism Adaptor: AL13GN2-B">Prism Adaptor: AL13G</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=1502"><img src="http://www.chinaexporter.com/file/upload/geomaster/SP-80S.JPG" width="80" height="80" alt="SP-80"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=1502" title="SP-80">SP-80</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=1484"><img src="http://www.chinaexporter.com/file/upload/geomaster/JS-716cb.jpg" width="80" height="80" alt="JS-716C"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=1484" title="JS-716C">JS-716C</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=2389"><img src="http://www.chinaexporter.com/file/upload/geomaster/20071120104425bts-802e.jpg" width="80" height="80" alt="BTS-802E"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=2389" title="BTS-802E">BTS-802E</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=2295"><img src="http://www.chinaexporter.com/file/upload/geomaster/200822516246pcc-3220.jpg" width="80" height="80" alt="PCC-3220"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=2295" title="PCC-3220">PCC-3220</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=2156"><img src="http://www.chinaexporter.com/file/upload/geomaster/200712310344PRS33.jpg" width="80" height="80" alt="PRS33"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=2156" title="PRS33">PRS33</a></li></ul></td> <td width="12.5%" valign="top"><a href="http://www.chinaexporter.com/seller/show.php?itemid=2157"><img src="http://www.chinaexporter.com/file/upload/geomaster/2007112014911ak104.jpg" width="80" height="80" alt="MPS104"/></a> <ul><li><a href="http://www.chinaexporter.com/seller/show.php?itemid=2157" title="MPS104">MPS104</a></li></ul></td> </tr></table> </div> </div> </div> <div class="m"> <br/> <center> [ <a href="http://www.chinaexporter.com/seller/search.php" rel="nofollow">ProductsSearch</a> ] [ <a href="javascript:SendFav();">Add To Favourite</a> ] [ <a href="javascript:SendPage();">Tell Friends</a> ] [ <a href="javascript:Print();">Print Content</a> ] [ <a href="javascript:SendReport();">Violation Report</a> ] [ <a href="javascript:window.close()">Close Window</a> ] </center> <br/> </div> <script type="text/javascript" src="http://www.chinaexporter.com/file/script/album.js"></script> <script type="text/javascript" src="http://www.chinaexporter.com/file/script/content.js"></script><div style="height: 3px;clear: both;"> </div> <div class="m_menu_foot"> <div class="m"> <div class="b10"> </div> <div class="three_part1"> <img src="http://www.chinaexporter.com/file/upload/201711/10/094314401.png"> <ul> <li class="menu_new">Our Network</li> <li><a href="http://www.isexporter.com/" target="_blank">智慧外贸通 isexporter.com</a></li> <li><a href="http://www.logisticsalliance.org/" target="_blank">全球物流联盟 logisticsalliance.org</a></li> </ul> </div> <div class="three_part2"> <ul> <li class="menu_new">General links</li> <li><a href="/extend/about.html">About us</a></li> <li><a href="/member/3aservice.php">3A member service</a></li> <li><a href="/ad/">Banner Advertisement</a></li> <li><a href="/extend/contact.html">Contact us</a></li> <li><a href="/member/grade.php">Member services</a></li> </ul> </div> <div class="three_part3"> <ul> <li><a href="https://www.facebook.com/eastraiseinternational/" class="pull-left social-icon social-facebook" data-toggle="tooltip" data-placement="top" title="" data-original-title="Facebook" aria-describedby="tooltip804896" target="_blank"> <i class="icon-facebook"></i> <i class="icon-facebook"></i> </a> <a href="http://www.twitter.com/chinaexporterc1/" class="pull-left social-icon social-twitter" data-toggle="tooltip" data-placement="top" title="" data-original-title="Twitter" aria-describedby="tooltip142168" target="_blank"> <i class="icon-twitter"></i> <i class="icon-twitter"></i> </a> <a href="https://plus.google.com/u/0/110747119662962238435" class="pull-left social-icon social-gplus" data-toggle="tooltip" data-placement="top" title="" data-original-title="Google+" aria-describedby="tooltip531200" target="_blank"> <i class="icon-gplus"></i> <i class="icon-gplus"></i> </a> <a href="https://www.linkedin.com/company/chinaexporter-com/" class="pull-left social-icon social-linkedin" data-toggle="tooltip" data-placement="top" title="" data-original-title="LinkedIn" aria-describedby="tooltip946500" target="_blank"> <i class="icon-linkedin"></i> <i class="icon-linkedin"></i> </a> <a href="https://www.instagram.com/chinaexporter.com1999/" class="pull-left social-icon social-instagram" data-toggle="tooltip" data-placement="top" title="" data-original-title="Instagram" aria-describedby="tooltip16737" target="_blank"> <i class="icon-instagram"></i> <i class="icon-instagram"></i> </a> <a href="http://skype.gmw.cn/" class="pull-left social-icon social-skype" data-toggle="tooltip" data-placement="top" title="" data-original-title="Skype" aria-describedby="tooltip476377" target="_blank"> <i class="icon-skype"></i> <i class="icon-skype"></i> </a> </li> </ul> </div> </div> </div> <div class="m"> <div class="foot"> <div id="copyright">copyright 1999-2024 金丝路数科 <a href="http://www.chinaexporter.com"> chinaexporter.com</a> <a href="http://beian.miit.gov.cn" target="_blank"> 津ICP备05014874号</a> </div> </div> </div> <script type="text/javascript"> $(function(){$("img").lazyload();});</script> </body> </html> <script type="text/javascript"> var _gaq = _gaq \|\| []; _gaq.push(['_setAccount', 'UA-34756409-1']); _gaq.push(['_setDomainName', 'chinaexporter.com']); _gaq.push(['_trackPageview']); (function() { var ga = document.createElement('script'); ga.type = 'text/javascript'; ga.async = true; ga.src = ('https:' == document.location.protocol ? 'https://ssl' : 'http://www') + '.google-analytics.com/ga.js'; var s = document.getElementsByTagName('script')[0]; s.parentNode.insertBefore(ga, s); })(); </script> <script type="text/javascript"> var _bdhmProtocol = (("https:" == document.location.protocol) ? " https://" : " http://"); document.write(unescape("%3Cscript src='" + _bdhmProtocol + "hm.baidu.com/h.js%3F8636a0ad51fad80c78a98e683f4c5cf4' type='text/javascript'%3E%3C/script%3E")); </script> <script type="text/javascript"> function googleTranslateElementInit() { new google.translate.TranslateElement({pageLanguage: 'en', includedLanguages: 'ar,de,es,fr,hi,id,it,iw,ja,ko,nl,pt,ru,th,tr,vi,zh-CN', layout: google.translate.TranslateElement.InlineLayout.SIMPLE, multilanguagePage: true}, 'google_translate_element'); } console.log($.cookie('iswall')); function checktrans(){ if ($.cookie('iswall')==null){ var img = new Image(); // 为Image对象添加图片加载成功的处理方法 img.onload = function() { $.cookie('iswall', '0', { expires: 30, path: '/', domain: 'chinaexporter.com' }); $.getScript("//translate.google.com/translate_a/element.js?cb=googleTranslateElementInit"); }; img.onerror= function() { $.cookie('iswall', '1', { expires: 30, path: '/', domain: 'chinaexporter.com' }); $.getScript("http://www.chinaexporter.com/file/script/trans.js"); setTimeout(function(){resetimg();},2000); }; // 开始加载图片 img.src = 'https://www.google.com/images/cleardot.gif'; } else if ($.cookie('iswall')=='1'){ $.getScript("http://www.chinaexporter.com/file/script/trans.js"); setTimeout(function(){resetimg();},2000); } else if ($.cookie('iswall')=='0'){ $.getScript("//translate.google.com/translate_a/element.js?cb=googleTranslateElementInit"); } } function resetimg(){ $('.goog-te-gadget-icon')[0].src=''; } checktrans(); </script>
