1. Approaches to select a floating fish feed equipment.
( 1) Appearance quality.
The spray paint externally of the shell of the drifting fish feed maker must be consistent and firm, as well as there must be no paint leakage, drooping and also falling off. The chrome-plated components need to be firm and vibrantly polished, free from peeling off and rust. Stainless steel parts ought to have a smooth surface area, no bumps, as well as must be refined with cool sleek patterns.
Related post: fish feed plant
( 2) Assembly as well as fastening
Along with checking the attachment of the body and also the framework, the electric motor (or diesel motor) as well as the framework, the floating fish feed device generally examines the setting up top quality of the template securing nut as well as the pellet cutter, and the ring die drifting fish feed maker mostly checks Whether the fastening bolts of the layout are tightened up. And also examine the rigidity of the pinch roller brace and pinch roller.
( 3) Readjust the space in between the die and also the pressure roller wall.
2 layers of paper are stuffed in between the stress roller and the internal wall surface of the ring die, and it can be pulled out with a little force. After modification, make certain to tighten the changing nut in time as well as install the safety cover.
Related post: Shrimp Feed Pellet Machine
After confirming that there are no international things in the guard and also the ring pass away, transform the ring die by hand. Right now, the driven pin needs to rotate quickly, and also there is no sticking phenomenon or rubbing audio.
2. Notes:
Directly observe whether there is whipping of the drifting fish feed machine ring pass away during turning as well as whether it will massage against various other components. Open the observation port for feeding the powder right into the turning cage and check whether there is any kind of contaminant in the turning cage.
Revolve the cage shaft by hand, the cage shaft should rotate efficiently and there is no massaging sound. Continuously open and shut the ring-molded warehouse door to check whether it is easy to open up as well as close and also securely shut.
Certain attention must be paid to inspecting the tightness of the joint and also the dependability of the securing. The basic requirements are: precise positioning, solid locking, as well as no leak of powder.
After locking the press chamber door, observe the seam seal of the chamber door from the side. If there is a place where the seal is not limited, the taking care of bolts of the door joint of the storage facility can be adapted to properly protect against the leak of powder.
3. Introduction of drifting fish feed maker
The floating feed extruder maker is a feed handling equipment that straight presses pellets from smashed materials such as corn, soybean meal, straw, yard, rice husk, etc( 1) Classification of floating fish feed pellet machine
Related post: Sinking Fish Feed Pellet Machine
floating fish feed machine can be divided right into ring pass away pellet equipment, ring die pellet device and also counter-roll pellet maker; according to production, it can be separated into: straw feed pellet machine, wheat bran feed pellet device, soybean meal feed pellet equipment, corn straw feed pellet device, Sawdust feed pellet equipment, and so on.
A variety of various floating fish feed makers are categorized according to their look and also production approaches.
( 2) Main efficiency qualities of drifting fish feed machine
Double shaft differential stainless steel conditioner, as much as 12 factors of heavy steam as well as 6 factors of liquid enhancement;
- Incorporated spindle, simple to preserve as well as repair the bearing housing;
- The screw and also the major shaft are connected by involute splines, which are simple to readjust and also change;
- The barrel is installed with a wear-resistant bushing and also is furnished with a return water network, which can be heated/cooled, and also can additionally directly inject steam or cold water right into the barrel;
- Spiral constructed from special wear-resistant product, huge element proportion can ensure constant and also secure manufacturing of sinking/floating feed of different pellet dimensions;
- Convenient and also quick die replacement device and also online flexible reducing device;
- Especially appropriate for the production of 2 ~ 6mm drifting pellets.
After the product is squeezed out by the drifting fish feed equipment, it will certainly create soft as well as soft pellets (the dampness material is 25%~ 30%). At this time, it is better to make use of pneumatic sharing instead of elevator.
Because the use of elevators can quickly trigger the pellets to be damaged and also boost the pulverization rate; the use of pneumatic communicating can not only promptly develop a layer of colloidal layer on the surface of the pellets to minimize the fragmentation of the pellets, however also round the shape of the pellets.
As a result of its high wetness web content, the product shared by pneumatic have to get in the clothes dryer for drying out, to ensure that the dampness material of the material is minimized to about 13%.
I hope the above relevant web content regarding floating fish feed device is useful to you. To learn more regarding drifting fish feed pellets machine, you are welcome to speak with the team of Richi Machinery, we will certainly serve you totally!
