LX Spiral Type Centrifugal Pump

Click image to view original image
Price: Negotiable
Min.Order:
Supply
Delivery: Shipment within 3 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2022-08-01 13:01
Hits: 18538
Enquiry
Company Detail


Details

China Spiral Centrifugal Pump Manufacturer Shinjo Supplies LX Spiral Type Centrifugal Pump, Flow Capacity 90 - 1400 m3/h Deliver Head From 15-30 Meters.


Introduction:
LX Spiral centrifugal pump can transport high concentration of slurry, and can transport the material containing large particles and long fiber, the open impeller (including closed) has a spiral blade, cone hub body by the entrance axial extension, the formation of spiral flow channel. The pump body is composed of suction tube and volute. The impeller of the suction pipe part produces spiral propulsion effect like spiral rod pump, and the impeller of the volute part produces centrifugal effect like general centrifugal pump. The acute Angle part of the blade inlet will guide the debris near the axis, and then screw it along the axial push, this is a positive displacement pump and centrifugal pump combined structure of the pump

Performance Range:
Capacity: 90 - 1400 m3/h
Delivery Head: 15-30 m
Size.: DN125-DN500 mm
Pump Material: Cast Iron
Suitable Medium: Clean Water (No solid contains)
Liquid Temperature: ≤ 80 ℃

Applications:

  • Sewage treatment field: high concentration of untreated sewage, sewage discharge, such as a large diameter pump to transport up to 1 meter of plastic braided belt through the test;
  • River dredging: silt, sand transport;
  • Paper industry: transport of high concentration pulp;
  • Marine fishing: transport live fish, live shrimp, etc.;
  • Food processing industry: transport potatoes, beets and other lumpy vegetables.
