JZX-10M Miniature Hermetically Sealed Relay

ENVIRONMENTAL CONDITIONS: Temperature Range: -55 ~ +85°C Relative Humidity: 98% at +40°C Atmospheric Pressure: 86~106kPa, Low pressure 4.4kPa Shock: 490m/s2 Vibration: 10~500Hz,98m/s2 Liner Acceleration: 245 m/s2 TECHNICAL DATA: Contact Arrangement: 2 Form C (DPDT) Coil Voltage: 6~60VDC,6.5mA~24mA Coil Dissipation: 0.16~0.57W Insulation Resistance: 1000MW Dielectric Withstanding Voltage (RMS/50Hz): 500~1000Vr.m.s. ContactRresistance: 0.05W Operate Time: 6ms Release Time: 4ms Contact Ratings: 2A28VDC Resistive,0.5A115VAC Resistive Electrical Life: 1 x105 Operations Leakage Rate: 1 x 100 Pa.cm3 /s Dimensions: 21 x 11 x 25 mm Weight: 20g Approved by Standards: QZJ840617
