GP Gravel Pump

Main Specifications

Size: 4-16 inches

Capacity: 36-5040 m3/h

Head: 5-80m

Material: Hi-chromium alloy

Seal: Packing seal, Expeller seal and Mechanical seal

Description

Our GP series gravel pumps could be wholly exchangeable with G&GH series gravel Warman pump. The GP pump is single-stage single-suction cantilever-type centrifugal pump, and adopts a single pump shell structure connected by clamps, with the advantage of light weight, good cavitation performance, strong corrosion resistance, wide flow channel, easy to install and maintenance etc. Our pumps could be used continuous for transport of large and strongly abrasive particles, which is much suitable for river channel dredging applications.

The main pump components are pump head, sealing parts, bearing assembling, pump frame. The bearing is lubricating with grease.

Pump Type Explanation

For Quick Selection Parameter
