| Accuracy | Upper Point:±10"; Downward: ±1'(±0.3mm/1m) | |||
| Laser Source(Visible Beam) | 635nm visible;Class II.<1mw | |||
| Power Supply | Rechargeable Batteries:DC:6V(Ni-H:5×1.2V) Continuous Working Time :Approx. 16Hrs | |||
| Ambient Temperature | -20°C ～ +50°C | |||
| Standard Accessories | Alkaline Batteries and its Housing Rechargeable Battery Pack,Adaptor(Charger) Laser Target,Plastic Carrying Case | |||
| Plumbing Beam Range | Upward:100m;Downward:5m | |||
| Spot Size(Emit Aperture) | Upward:Ø15mm;Downward:Ø6mm | |||
| Compensation System | E-sensor:Self-leveling | |||
| Compensation Range | Upward:±3°;Downward:±2.5° | |||
| Water-proof and Dust-proof | IP×6 | |||
| Dimensions(L×W×H) | 170mm×170mm×241mm(N.W.:2.5kg) | |||
| Shipping Carton Details | 1pc per Carton;6.00 kgs per Carton Dimensions per Carton;0.06CBM(51cm×31cm×38cm) | |||
| Features | 1.Equipped with hi-accuracy 3-axis compensator for fast and automatic leveling. 2.Visible and "Bull's eye" plumbing beams for easy,fast and precise alignment. 3.With a wide plumbing range (Upward:100m;downward:5m) 4.Ideal for alignment of tall buildings and high objects. | |||
| Note | The Specifications would be subject to change without prior notice! | |||
