Item |
Technical Parameters |
|
Micron(µm ) |
0.1, 0.22, 0.45, 1, 2, 3, 5, 10, 20, 30, 60 |
|
Filtration area |
0.4-0.7m² |
|
Filter Media |
Polypropylene |
|
Support/Drainage |
Polypropylene |
|
Core/Cage/End Cap |
Polypropylene |
|
Outside diameter |
68.5mm |
|
Maximum operating differential pressure |
ΔP≤0.35MPa at25℃ |
|
Maximum operating differential pressure (reverse direction) |
ΔP≤0.28MPa at60℃ |
|
Maximum operating temperature |
80℃（Stainless steel support is recommended for temperature exceeds 50℃） |
|
Sterilization temperature |
30 minute cycles @121℃ |
|
Maximum operating pressure |
4bar/21℃ |
|
2.4bar/80℃ |
