Size: 50-150mm
Capacity: 20-150m3/h
Head: 8-20m
Medium temp.: ≤70℃
Concentration:50-60%
Materials: Cast iron, Cast steel, SS304, SS316L etc.
Tobee® TNL Vertical Sludge Pump is single-stage, single-suction, vertical centrifugal pump, it is designed for delivering highly abrasive, large particles and high density sludges, with advantages of small leak loss, with characteristics of good performance, high efficiency, low energy consumption, TNL sludge pumps wetted parts are made from wear resistant alloys, Widely used for Draining the mortar under the river and lake, sludge impurity in pond, mud in sewage pool, sands, waste water, floodwater, coal washery, bentonite, chemical fertilizer, paper pulp, mining slurries etc.
Design Features:
• Single-stage, single-suction, centrifugal,vertical sludge pump design
• The impeller is composite of 3 vanes and single round string, semi-open, makes a good performance of passing and high efficiency.
• The pumps casing installed four oil seal to prevent the shaft and extend the life of the shaft.
• The Wear parts are made of high anti-wear alloys
• The Length of shaft can be Customized.
