Click image to view original image
1.Hazardous division 1&2,or 20 or 21,&22
2.Explosive gas atmosphere;class IIA,IIB,IIC or inflammable dust environment.
3.Indoor or outdoor IP66
4.The glands is widely used in the fields of oil,chemical industry,aerospace,military and so on.
Product features
Execution standard:GB3836.1,GB3636.3
Explosion proof mark:ExdIIC Gb
Thread:Metric is standard,if there is special
requirement,such as G,NPT thread,please specify When ordering.
Product materials:304SS,316L,H62
Outline dimension
The technical reference
| Metric(M) | G | Outer diameter of cable (mm) | GL (mm) | Length (mm) | Length (mm) | Ex-mark | Protection Level | |
| Outlet A | Inlet B | |||||||
| M16*1.5 | ----- | 8 | 7-15 | 15 | 68 | 85 |
Exd IIC Gb |
IP66 |
| M20*1.5 | G1/2 | 8 | 7-15 | 15 | 68 | 85 | ||
| M25*1.5 | G3/4 | 13 | 11-20 | 15 | 72 | 87 | ||
| M32*1.5 | G1 | 16 | 14-25 | 15 | 77 | 92 | ||
| M40*1.5 | G1 1/4 | 21 | 19-33 | 15 | 77 | 95 | ||
| M50*1.5 | G1 1/2 | 25 | 24-41 | 15 | 95 | 100 | ||
| M63*1.5 | G2 | 32.5 | 30-50 | 15 | 99 | 110 | ||
| M75*1.5 | G2 1/2 | 44 | 38-64 | 15 | 113 | 127 | ||
| M85*1.5 | G3S | 52 | 47-74 | 15 | 113 | 127 | ||
| M90*1.5 | G3 | 52 | 47-74 | 15 | 127 | 137 | ||
| M100*1.5 | G4S | 64 | 57-90 | 15 | 127 | 137 | ||
| M110*1.5 | G4 | 72 | 62-103 | 15 | 127 | 137 | ||
For the glands,we can also provide the pipe wiring connector,if needed,welcome to contact with us.
Customization is accepted
