Feature and function
1.Put a roll in the form of flat belt push, equipped with stepless speed regulating device, rolling tension can be adjusted.
2.Embossed steel roller on wool roller (according to customer requirements using other material embossing roll).
3.Folding adopt vacuum adsorption form.
4.Each part adopt synchronous belt.
5. Can produce different specifications of the models according to the requirement, can increase 1-4 color flexo printing device.
Technical parameters
grammage
13-20g/m
Stable production speed
500-600pcs/min
Unfold size
W:140-210mm
Folding dimensions
（68-115）×（50-83）mm
The diameter of Jumbo Roll paper
≤1200mm
A roll of paper specification
13-16g/m2(3ply) 17-22g/m2(2ply)
Installed power
1.5KW
The vacuum fan power
3.0KW
Voltage
220/380 V
Equipment weight
≈ 1.2T
