It is applicable to explosive gas environment zone1 and zone2.
It is applicable to explosive dust atmosphere district 20,21 and 22.
It is suitable for IIA,IIB,IIC explosive gas environment.
Outline dimension
Execution standard:GB3836.1,GB3636.3
Explosion proof mark: Exd IIC Gb/Exe II G/Ex tD A21 IP68
Thread:Metric is standard,if there is special requirement,such as G,NPT thread,please specify When ordering.
Product materials:304SS,316L,H62
(D1)Specifications
(Φ)Cable diameter
Thread length
Length
()Armored cable diameter (outlet)
()Cable diameter(inlet)
Standard
Optional(K)
M20*1.5A
G1/2"A
<10.5
--
5.5-12
15
89
M20*1.5B
G1/2"B
<10.5
--
9.5-16
15
89
M20*1.5C
G1/2"C
<14.5
6-12
12.5-20.5
15
91
M25*1.5B
G3/4"B
<14.5
6-12
12.5-20.5
15
91
M25*1.5C
G3/4"C
<16.5
9-15
17-26
15
98
M32*1.5B
G1"B
<19.5
9-15
17-26
19
106
M32*1.5C
G1"C
<22.5
14-22
22-33
19
114
M40*1.5B
G1 1/4"B
<25.5
14-22
22-33
19
114
M40*1.5C
G1 1/4"C
<29
19-28
28-41
19
121
M50*1.5B
G1 1/2"B
<31
19-28
28-41
19
121
M50*1.5C
G1 1/2"C
<37
26-33
36-52.5
19
129
For more details,welcome to check with us or check our website:www.exproofcablegland.com
