Oil, Natural Gas Steel Pipe Production Line

Click image to view original image
Brand: Zhonghui
Price: 100.00USD/set
Min.Order: 1 set
Supply
Delivery: Shipment within 9 days since the date of payment
Address: China
Valid until: Never Expire
Updated on: 2019-05-17 15:40
Hits: 18808
Enquiry
Company Detail


Details

Quick Information

  • Brand Name:Zhonghui
  • Place of Origin:China

Description

Brief Description:

This line is designed to produce the oil and gas transmission pipe, petroleum driven pipe etc, conforming to standard of API-5L、API-5CT、ASTM A53 Grade A&B, also the boil and heat transfer pipes, high-pressure pipes etc.
We absorbed the international advanced technology of tube making, like FFX and cage forming flexible formation technology etc, which apply CAD system to deformation process of welding pipe, which analysis and research the distortion craft of high grade steel pipe, also coordinated with high-performance welding machine to solve better the forming and welding defects that provide the high grade & high value-added welded pipe products for users.


Value Highlights: Saving the rollers
                  Strong stands

Main technical parameters


Model Material of strip steel: carbon steel of σb≤580Mpa, σs≤350MPa and low alloy steel of ≤X80 Production speed(m/min)
Diameter of welded pipe(mm) Thickness of welded pipe(mm)
HG114 Ø48~ Ø114 1.5~5.0 20~60
HG140 Ø48~ Ø140 1.5~5.0 20~60
HG165 Ø60~ Ø165 2.0~6.0 10~45
HG219 Ø89~ Ø219 3.0~8.0 10~35
HG273 Ø114~ Ø273 4.0~12.7 10~35
HG325 Ø165~ Ø325 4.0~12.7 10~35
HG426 Ø165~ Ø426 6.0~16.0 10~35
HG508 Ø219~ Ø508 6.0~16.0 10~35
HG610 Ø219~ Ø610 6.0~18.0 10~25






Price

  • Delivery Port :Tianjin

Packaging & Delivery

  • Packing :By carton box or Wooden box according to different
  • Delivery Lead Time :3-7 working days according to different quantities
  • Supply Ability :100/sets per month

Product Image

  • Oil, Natural Gas Steel Pipe Production Line image
