APPLICATIONS
Stainless steel upper pans
High-strength stainless steel body.
Platform size and capacity made to customers' order
DC/AC power and LED monitor with background lignting.
Unit indication selection: kg,lb and customized unit
RS-232
High stability: particularly suitable for weighing flowls and aquatics to obtain a stable and business use.
This product can be widely ued in industry, agriculture, animal husbandry, business use.
plate Size(mm) |
platform size material(mm) |
Thickness plate(mm) |
plate Size(mm) |
platform size material(mm) |
Thickness plate(mm) |
300*300 | 30*30*2 | 1.2 | 450*600 | 40*40*2.5 | 1.2 |
1.5 | 1.5 | ||||
300*400 | 30*30*2 | 1.2 | 2 | ||
1.5 | 500*600 | 40*40*2.5 | 1.5 | ||
350*450 | 40*40*2 | 1.2 | 2 | ||
1.5 | 600*600 | 40*40*2.5 | 1.5 | ||
400*400 | 40*40*2 | 1.2 | 2 | ||
1.5 | 600*600 | 50*50*3 | 1.5 | ||
450*450 | 40*40*2 | 1.2 | 2 | ||
1.5 | 600*700 | 50*50*3 | 1.5 | ||
400*500 | 40*40*2 | 1.2 | 2 | ||
1.5 | 600*800 | 50*50*3 | 1.5 | ||
2 | 2 | ||||
450*550 | 40*40*2.5 | 1.2 | 700*800 | 50*50*3 | 1.5 |
1.5 | 2 | ||||
2 | 800*800 | 50*50*3 | 2 |
