seline;="" background-color:="" rgb(153,="" 153,="" 153);"="" style="margin: 0px; padding: 0px; position: relative; display: inline-block; word-break: break-all; box-sizing: content-box; border: 0px; font-style: inherit; font-variant: inherit; font-weight: inherit; font-stretch: inherit; font-size: 16px; line-height: 24px;">Dimensions
seline;"="" style="margin: 0px; padding: 0px; position: relative; display: inline-block; word-break: break-all; box-sizing: content-box; border: 0px; font-style: inherit; font-variant: inherit; font-weight: inherit; font-stretch: inherit; font-size: 16px; line-height: 24px;">*customsize is availableseline;"="" style="margin: 0px; padding: 0px; position: relative; display: inline-block; word-break: break-all; box-sizing: content-box; border: 0px; font-style: inherit; font-variant: inherit; font-weight: inherit; font-stretch: inherit; font-size: 16px; line-height: 24px;">
| Model | Width | Height | Depth | Filter area | Airflow and pressure drop | frame | |
| (mm) | (mm) | (mm) | (m2) | (m3/h&pa) | |||
| BKL24×24×4 | 594 | 594 | 96 | 2.66 | 1700/18 | 3400/68 | Aluminium alloy |
| BKL24×12×4 | 594 | 289 | 96 | 1.3 | 850/18 | 1700/68 | Aluminium alloy |
| BKL24×20×4 | 594 | 492 | 96 | 2.2 | 1420/18 | 2840/68 | Aluminium alloy |
| BKL20×20×4 | 492 | 492 | 96 | 1.82 | 1180/18 | 2360/68 | Aluminium alloy |
| BKL20×16×4 | 492 | 391 | 96 | 1.45 | 935/18 | 1870/68 | Aluminium alloy |
| BKL25×20×4 | 619 | 492 | 96 | 2.3 | 1480/18 | 2960/68 | Aluminium alloy |
| BKL25×25×4 | 619 | 619 | 96 | 2.9 | 1860/18 | 3720/68 | Aluminium alloy |
| BKL24×24×2 | 594 | 594 | 46 | 1.75 | 1700/20 | 3400/70 | Aluminium alloy |
| BKL24×12×2 | 594 | 289 | 46 | 0.85 | 850/20 | 1700/70 | Aluminium alloy |
|
|
|||||||
