Dimension of sliding table |
2800*375mm |
|
Gross cut capacity |
2800mm |
|
Width of cut between saw blade and ripe fence |
1250mm |
|
Saw blade |
300mm (250-300) |
|
Height of cut 300mm |
70mm |
|
Speed of main saw blade |
6000r.p.m |
|
Tiling saw blade |
45 Degree |
|
Main motor |
4kw(5.5kw for option） |
|
Scoring saw blade diameter |
120mm |
|
Speed of scoring saw blade diameter |
8000r/min |
|
Scoring motor |
0.75kw(1.1kw for option） |
|
Net weight |
680kg |
|
Overall dimensions |
2800*2550*900mm |
|
Loading 20GP/40HQ |
10 SETS/22SETS |
