Outer case
black case
Dimension
Tiger shark DS-4 342mmx99mm x78mm Tiger shark DS-6C 377mmx132mm x78mm
Standard Charge
Constant Current 0.2C, Constant Voltage 42V 100mA Cut-off
Fast Charge
Constant Current 0.5CA, Constant Voltage 42V 100mA Cut-off
Standard Discharge
Constant Current 0.2C/End Voltage 39V
Cycle Life
500 times with DOD80%
Continuous Discharge Current
10A
Peak discharge current
30A
BMS function
Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Balance
Storage Temperature Range
Temperature: -10-40℃
Relative humidity:45-75%
Pressure: 86-106KPa
Tiger shark DS-4C 378mmx99mm x78mm
Tiger shark DS-5 344mmx114mm x78mm
Tiger shark DS-5C 379mmx114mm x78mm
Tiger shark DS-6 342mmx132mm x78mm
