AUTOID6L-W is a handheld terminal designed for high strength inner-field application with Windows CE operation system. It could be operated by single hand in various hard environment, which could scan more than 3000 barcode per day.
-----------------------------------------------------------
ConTACT US
Website:en.seuic.com
Mail:marketing@seuic.com
-----------------------------------------------------------
| CPU | Ti ARM® Cortex™-A8 AM3715/DM3730 1GHz |
| Operating System | Microsoft® Windows® CE 6.0 |
| RAM | 512MB |
| ROM | 512MB |
| User Storage | 4GB (Built-in and irremovable) |
| Storage Expansion | Micro SD Card, 32GB SDHC compatible |
| Interface/Communication | Standard Micro USB interface, Support USB2.0 High Speed |
| Keypad | 28keys |
| LED (buttons with backlight) | |
| Display | 3.5" industrial color LCD, resistive touch,320*240 |
| Power Supply | Removable 3.7V 3800mAh rechargeable Li-ion battery |
| Built-in backup battery: non-removable 3.7V/100mAh rechargeable battery | |
| Charging | Special 5V voltage charger, 1.5A currentPC USB charging 0.5A currentIntelligently identify PC and special charger to switch 0.5A/1.5A charging current |
| Notification | Sound, Vibrator, LED indicator |
| Audio | Built-in loudspeaker |
| Dimension | 169(H) ×72(W) ×36(T) mm, (width 72mm without side keys) |
| Weight (including standard battery) | 313g (Including battery depends on different configurations) |
| Operating Temp |
-20℃ to +50℃ |
