100% copper wire
stable running, high efficiency, low noise
good service after sale
12V, 24V, 48V, etc. on your request
Customized production is available!
Supply for OEM Production!
nearly 15 years' manufacturing experience
Specification:
1) Type:HY61041
2) Voltage: 12V
3) Power: 1.2KW
4) Rotation Speed: ≥ 2550rpm
5) Rotation Direction: CW
6) O.D. : 114mm or 4.5 inch
7)Operating mode: S2-2.5min
8) Insulation Class: F
9) Protection Degree: IP 54
| Type | Size | Rated voltage | Nominal power | Rotation speed | Rotation direction | Torque | Surface color |
| HY61041 | 4.5'' | 12V | 1.2KW | ≥ 2550rpm | CW | ≥ 4.5N.m | Red |
Packaging
All motors are packaged by pallet to protect them during delivery!
