TL Series Vertical Pit Desulphurization Pump
Product Description
- Single stage, single suction, vertical centrifugal pump
- Wet parts such as casing, impeller, liner plate in anti-abrasion and corrosion-resistant high chrome cast iron alloy.
- For fluid of high concentration, inlet agitator is designed
-According to the depth of the pit, suction pipe can be added to the pump inlet.
- Hydraulic optimization design and stable operation
Technical Specifications
Performance and Main Technical Datas of TL Desulphurizations Pumps
|
Type |
Allowable |
Clear water |
Particle max.
Size handled (mm) |
Pump weight (kg) |
||||
|
Q Capacity (m3/h) |
H Head (m) |
n Speed (r/min) |
Max.eff. (%) |
(NPSH)r (m) |
||||
|
150TL-A35 |
30 |
99-364 |
3.0-17.9 |
490-980 |
69.0 |
/ |
15 |
712 |
|
100TL-A34 |
45 |
74-293 |
5.5-36.8 |
700-1480 |
65.8 |
/ |
14 |
502 |
|
80TL-A45 |
110 |
59-286 |
12.5-81.6 |
700-1490 |
58.4 |
/ |
15 |
785 |
|
80TL-A36 |
45 |
50-201 |
7.3-45.5 |
700-1480 |
58.2 |
/ |
12 |
645 |
|
65TL-A40 |
45 |
30.2-142.8 |
10.2-62.6 |
700-1480 |
50.0 |
/ |
12 |
658 |
